Description:
■ ) The tube voltage frequency of this machine is 30 KHz, and the tube current is 0.2 MA. The radiation scope is at an angle of 24 degrees, located within a distance of 1.2 meters ahead.
■ ) To shiba 0.3mm x 0.3mm micro-focus tube
■ ) No protective operation room is needed when installing the complete machine.
■ ) Flexible adjustment of position and angle of handpiece
■ ) Compact in volume, light in weight, convenient for carrying
■ ) Time is adjustable, high contrast of picture, imaging in focus
■ ) There are vacuum components and high-pressure parts inside of the machine, so for your safety and the maintenance of the machine
■ ) The tube head is equipped with excellent radiation-shield protection (except the radial mouth, and tests have shown that the radial index is zero. Safety is guaranteed.
■ ) Non-film inspection and storage can be realized when corresponding to a sensor.
Specifications:
■ Voltage:230V
■ Power: 24V 8000MA
■ Charger: 230V, 50Hz
■ Tube current: 0.1mA
■ Rating: 60W
■ Frequency: 30 KHz
■ Exposure time: 1-9 seconds optional
■ Leak radiation: < 20μgy/h(12lb)
■ Focus Skin Distance: >20cm
■ Tube voltage: 60KV
■ Relative Humidity(RH) < 80%
■ Storage conditions: 5-40 degrees Celsius, relative Humidity
Operation of the Main Unit:
■ Upon receiving, open the box and check the product for possible damage during shipping.
■ Make sure the fittings on the encasement list are packaged within the box.
